1. FS-031 series Fuse Holders,
Rated voltage/current: AC/DC 3 V~800 V/32 A, 1~3P available. FS-031, FS-032, FS-033.
Suitable for 10x38 mm fuse. Embedded Rail Adapter for 35mm DIN Rail. Without LED indicator.
享曆 FS-031系列 保險絲座,
額定電壓: AC/DC 3V~800V, 額定電流rent: 32 A, 電極P數: 1~3P, FS-031, FS-032, FS-033。
適用保險絲規格: 10x38 mm保險絲。內建軌道轉接器可安裝固定在35mm寬的軌道上。
2. FS-031L1 series Fuse Holders,
Rated voltage/current: 12 V~120 V/32 A, 1~3P available. FS-031L1, FS-032L1, FS-033L1. (FS-031L1 is UL/cUL approved.)
Suitable for 10x38 mm fuse. Embedded Rail Adapter for 35mm DIN Rail. Embedded LED indicator.
享曆 FS-031L1系列 保險絲座,
額定電壓: 110 V (12 V~120 V), 額定電流: 32 A, 電極P數: 1~3P, FS-031L1, FS-032L1, FS-033L1。
適用保險絲規格: 10x38 mm 保險絲。內建軌道轉接器可安裝固定在35mm寬的軌道上。 內建斷電指示燈。
3. FS-031L2 series Fuse Holders,
Rated voltage/current: AC 380 V/32 A, 1~3P available. FS-031L2, FS-032L2, FS-033L2. (FS-031L2 is UL/cUL approved.)
Suitable for 10x38 mm fuse. Embedded Rail Adapter for 35mm DIN Rail. Embedded LED indicator.
享曆 FS-031L2系列 保險絲座,
額定電壓: 380 V, 額定電流: 32 A, 電極P數: 1~3P, FS-031L2, FS-032L2, FS-033L2。
適用保險絲規格: 10x38 mm 保險絲。內建軌道轉接器可安裝固定在35mm寬的軌道上。 內建斷電指示燈。
4. FS-031L3 series Fuse Holders,
Rated voltage/current: AC 600 V/32 A, 1~3P available. FS-031L3, FS-032L3, FS-033L3. (FS-031L3 is UL/cUL approved.)
Suitable for 10x38 mm fuse. Embedded Rail Adapter for 35mm DIN Rail. Embedded LED indicator.
享曆 FS-031L3系列 保險絲座,
額定電壓: 600 V, 額定電流: 32 A, 電極P數: 1~3P, FS-031L3, FS-032L3, FS-033L3。
適用保險絲規格: 10x38 mm 保險絲。內建軌道轉接器可安裝固定在35mm寬的軌道上。 內建斷電指示燈。
5. FS-011B (/FS-012B/.../FS-018B) series 10A Fuse Holders.
Fuse holder Rated voltage/current:600V/10A, for 6x30 mm (1/4"x1 1/4" ) fuse use.
1~8P available: FS-011B, FS-012B, FS-013B, FS-014B, FS-015B, FS-016B, FS-017B, FS-018B fuse holder, suitable for 35mm DIN Rail. Fast installation and release.
Additional Power-Off / Power Failure Indicators are optional.
FS-011B系列 10安培保險絲座, 保險絲座
額定電壓: 600V, 額定電流: 10A, 適用保險絲規格: 6x30 mm (1/4"x1 1/4" )
P數:1~8P FS-011B, FS-012B, FS-013B, FS-014B, FS-015B, FS-016B, FS-017B, FS-018B, 可直接鎖螺絲安裝固定在機板上或固定在35mm軌道上。快速安裝與拆卸。
6. UL certificated fuse block, fuse holder with UL approval. FB-M031PQ series Midget Fuse Blocks.
Fuse blocks with Rated voltage/current: 600 V/30 A, 1~3P available. FB-M031PQ, FB-M032PQ, FB-M033PQ midget fuse block. Suitable for 10x38 mm (13/32"x 1 1/2") fuse. Apply 35mm DIN Rail. Additional Power-Off, Power Failure Indicator Available.
FB-M031PQ系列 30安培保險絲盒,
額定電壓: 600 V, 額定電流: 30 A, P數: 1~3P( FB-M031PQ, FB-M032PQ, FB-M033PQ)
接線端子類型：採用壓板固定導線，並且另外提供快速連接端子可供連接。安裝方式：可用螺絲直接將保險絲盒安裝固定在機板上。
適用保險絲規格 10x38 mm (13/32"x 1 1/2")。另有軌道轉接器DRA可安裝固定在35mm寬軌道上，以及斷電指示燈FB-030可選購。
7. UL certificated fuse holder, fuse blocks UL approved. FB-M031SQ series Midget Fuse Blocks.
Fuse block with rated voltage/current: 600 V/30 A, 1~3P available. FB-M031SQ, FB-M032SQ, FB-M033SQ midget fuse block. Suitable for 10x38 mm (13/32"x 1 1/2") fuse. Apply 35mm DIN Rail. Additional Power-Off / Power Failure Indicator Available.
FB-M031SQ系列 30安培保險絲盒,
保險絲盒的額定電壓: 600 V, 額定電流: 30 A, P數: 1~3P( FB-M031SQ, FB-M032SQ, FB-M033SQ)
接線端子類型：採用螺絲鎖緊固定導線，並且另外提供快速連接端子可供連接。安裝方式：可用固定螺絲將保險絲盒直接安裝固定在機板上。
適用保險絲規格 10x38 mm (13/32"x 1 1/2")。另有軌道轉接器DRA可安裝固定在35mm寬軌道上，以及斷電指示燈FB-030可選購。
